N02200 Nicel 200 dur Plate taflen Coil
N02200 Nicel 200 dur Taflen plât Enw Coilproduct; deunydd PLATE; N02200 Nicel 200
N02200 Nicel 200 dur Plate taflen Coil
Rhif UNS N02200
Enwau cyffredin eraill: Nickel 200
Ar ba ffurf mae Nickel 200 ar gael?
• Cynfas
• Plât
• Bar
• Pibell a thiwb (weldio a di-dor)
• Gwifren
Dadansoddiad Cemegol
Pwysau % (uchafswm yw pob gwerth oni nodir amrediad fel arall)
| Elfen | Nicel 200 | Nicel 201 |
|---|---|---|
| Nicel (a Cobalt) | 99.0 lleiafswm | 99.0 lleiafswm |
| Copr | 0.25 | 0.25 |
| Haearn | 0.40 | 0.40 |
| Manganîs | 0.35 | 0.35 |
| Carbon | 0.15 | 0.02 |
| Silicon | 0.35 | 0.35 |
| Sylffwr | 0.01 | 0.01 |
Priodweddau Corfforol
Dwysedd
0.321 pwys/mewn38.89 g/cm3
Gwres Penodol
0.109 BTU/lb- gradd F (32-212 gradd F)456 J/kg- gradd K (0—100 gradd)
Modwlws Elastigedd 78 gradd F (26 gradd)
29.7 x 103 ksi205 GPa ( 20 gradd )
Dargludedd Thermol 212 gradd F ( 100 gradd )
463 BTU-in/ft2-h- gradd F66.5 W/m- gradd
Ystod Toddi
2615 - 2635 gradd F1435 - 1446 gradd
Gwrthiant Trydanol
58 Ohm-circa mil/ft ar 70 gradd F0.096 µΩ/m ar 20 gradd
Ehangiad Llinol Cymedrig
| Amrediad Tymheredd | Cyfernod Ehangu | ||
|---|---|---|---|
| gradd F | gradd | 10-6 mewn/mewn gradd F | gradd µm/m |
| -423 | -200 | 4.7 | 10.1 |
| -300 | -100 | 5.8 | 11.3 |
| -200 | 20 | 6.2 | — |
| -100 | 100 | 6.3 | 13.3 |
| 0 | 200 | — | 13.9 |
| 70 | 300 | — | 14.2 |
| 200 | 400 | 7.4 | 14.8 |
| 400 | 500 | 7.7 | 15.3 |
| 600 | 600 | 8.0 | 15.5 |
| 800 | 700 | 8.3 | 15.8 |
| 1000 | 800 | 8.5 | 16.2 |
| 1200 | 900 | 8.7 | 16.6 |
| 1400 | 1000 | 8.9 | 16.9 |
| 1600 | 1100 | 9.1 | 17.1 |
| 1800 | 9.3 | ||
| 2000 | 9.5 | ||
Priodweddau Mecanyddol
Nicel 200, Gwerthoedd Nodweddiadol ar 70 gradd F (21 gradd ), Plât - Rholio Poeth, Wedi'i Anelio
| Cryfder Cynnyrch 0.2% Gwrthbwyso |
Tynnol Ultimate Cryfder |
Ymuniad mewn 2 fodfedd |
Caledwch | ||||
|---|---|---|---|---|---|---|---|
| ksi | Mpa | ksi | Mpa | % | Brinell (3000-kg) |
Rockwell B |
|
| Nicel 200 | 15–40 | 105–275 | 55–80 | 380–550 | 60–40 | 90–140 | 45–73 |
